Simbologia |
Tipo |
Q max. l/min |
P max. bar |
Azionamento |
Foro Filettatura |
Scheda tecnica |
Scheda tecnica |
|
WS…/WR…/WK… |
0 |
0 |
descrizione |
|
WS,WR,WK-5_400-P-120100-en |
|
WSP22G-1-AL |
5 |
420 |
elettromagnetico |
AL 3/4-16 UNF |
WSP22G-1-AL_400-P-120601-en |
|
WSP22O-1-AL |
5 |
420 |
elettromagnetico |
AL 3/4-16 UNF |
WSP22O-1-AL_400-P-120602-en |
|
WSP22O-3-AL |
15 |
420 |
elettromagnetico |
AL 3/4-16 UNF |
WSP22O-3-AL_400-P-120802-en |
|
WSP22G-3-AL |
15 |
420 |
elettromagnetico |
AL 3/4-16 UNF |
WSP22G-3-AL_400-P-120801-en |
|
W1T / W… (shallow) |
40 |
315 |
taratura manuale |
AA ad innesto |
W1T-W1W-installation-shallow_400-P-110310-en |
|
W1T / W… (deep) |
40 |
315 |
taratura manuale |
AB ad innesto |
W1T-W1W-installation-deep_400-P-110311-en |
|
W1Q… |
40 |
315 |
pneumatico |
AA ad innesto |
W1Q_400-P-110410-en |
|
EEx-W1C… |
20 |
315 |
elettromag. EEx |
AA ad innesto |
EExW1C-6_400-P-110210-en |
|
WS22G-5-AL |
30 |
250 |
elettromagnetico |
AL 3/4-16 UNF |
WS22G-5-AL_400-P-121100-en |
|
WS22G-5-ALM |
30 |
250 |
elettromagnetico |
ALM M20 x 1,5 |
WS22G-5-ALM_400-P-121101-en |
|
WS22O-5-AL |
30 |
250 |
elettromagnetico |
AL 3/4-16 UNF |
WS22O-5-AL_400-P-121102-en |
|
WS22O-5-ALM |
30 |
250 |
elettromagnetico |
ALM M20 x 1,5 |
WS22O-5-ALM_400-P-121103-en |
|
WS22G / OD... |
30 |
350 |
digitale |
AL 3/4-16 UNF |
WS22-D-5_400-P-121110-en |
|
WS22G / OD... |
30 |
350 |
digitale |
ALM M20 x 1,5 |
WS22-D-5_400-P-121110-en |
|
W1… |
40 |
315 |
descrizione |
|
W1-Overview_400-P-105010-en |
|
W1C…(shallow) |
40 |
315 |
elettromagnetico |
AA ad innesto |
W1C-installation-shallow_400-P-110111-en |
|
W1C…(deep) |
40 |
315 |
elettromagnetico |
AB ad innesto |
W1C-installation-deep_400-P-110112-en |
|
WSDPP32G-5P... |
32 |
420 |
elettromagnetico |
GP/C0830 3/4-16 UNF |
WSDPP32G-5-GP_400-P-121210-en |
|
WSD22G-8X-… |
60 |
315 |
elettromagnetico |
AX/C1020 7/8-14 UNF |
WSD22G-8X_400-P-122150-en |
|
WS22GPRSADC-10… |
80 |
350 |
monitoraggio della posizione tramite interruttore |
DD M24 x 1,5 |
WS22GPS-10-DD_400-P-131105-en |
|
WSVN22G-10F… |
140 |
350 |
elettromagnetico |
HF/C1220A 1 1/16-12 UN |
WSVN22G-10-HF_400-P-131310-en |
|
WSVN22G-10A… |
140 |
350 |
elettromagnetico |
HA/C1220 1 1/16-12 UN |
WSVN22G-10-HA_400-P-131300-en |
|
WSVN22O-10A… |
140 |
350 |
elettromagnetico |
HA/C1220 1 1/16-12 UN |
WSVN22O-10-HA_400-P-131301-en |
|
WSVN22O-10F… |
140 |
350 |
elettromagnetico |
HF/C1220A 1 1/16-12 UN |
WSVN22O-10-HF_400-P-131311-en |
|
WS22GC-10-DC |
140 |
350 |
elettromagnetico |
DC M24 x 1,5 |
WS22GC-10-DC_400-P-131101-en |
|
WS22OC-10-DC |
140 |
350 |
elettromagnetico |
DC M24 x 1,5 |
WS22OC-10-DC_400-P-131107-en |
|
WS22GD-10-DD |
140 |
350 |
elettromagnetico |
DD M24 x 1,5 |
WS22GD-10-DD_400-P-131106-en |
|
WS22OD-10-DD |
140 |
350 |
elettromagnetico |
DD M24 x 1,5 |
WS22OD-10-DD_400-P-131108-en |
|
WS22OH-10-DH |
140 |
350 |
elettromagnetico |
DH M27 x 2 |
WS22OH-10-DH_400-P-131103-en |
|
WS22GH-10-DH |
140 |
350 |
elettromagnetico |
DH M27 x 2 |
WS22GH-10-DH_400-P-131102-en |
|
WS22G / O… |
350 |
420 |
elettromagnetico |
EB M42 x 2 |
WS22-16_400-P-150101-en |
|
|
WR22GA5... |
40 |
350 |
elettromagnetico |
AL 3/4-16 UNF |
WR22GA5_400-P-121120-en |
|
WR22OA5... |
40 |
350 |
elettromagnetico |
AL 3/4-16 UNF |
WR22OA5_400-P-121126-en |
|
WR22GPSAB5… |
40 |
350 |
monitoraggio della posizione tramite interruttore |
AL 3/4-16 UNF |
WR22GPS-5-AL_400-P-121125-en |
|
WR22GZ5... |
40 |
350 |
elettromagnetico |
ALM M20 x 1,5 |
WR22G-5-ALM_400-P-121123-en |
|
WR22OZ5... |
40 |
350 |
elettromagnetico |
ALM M20 x 1,5 |
WR22OZ5_400-P-121127-en |
|
WR22KA5... |
40 |
350 |
elettromagnetico |
AL 3/4-16 UNF |
WR22KA5_400-P-121141-en |
|
WR22LA5... |
40 |
350 |
elettromagnetico |
AL 3/4-16 UNF |
WR22LA5_400-P-121142-en |
|
WR22LZ5... |
40 |
350 |
elettromagnetico |
ALM M20 x 1,5 |
WR22LZ5_400-P-121143-en |
|
WR22KZ5... |
40 |
350 |
elettromagnetico |
ALM M20 x 1,5 |
WR22KZ5_400-P-121140-en |
|
WRP22G5... |
40 |
420 |
elettromagnetico |
AL 3/4-16 UNF |
WRP22G5_400-P-121121-en |
|
WRP22O5... |
40 |
420 |
elettromagnetico |
AL 3/4-16 UNF |
WRP22O5_400-P-121122-en |
|
WRVP22G-8X |
80 |
350 |
elettromagnetico |
AX/C1020 7/8-14 UNF |
WRVP22G-8-AX_400-P-122120-en |
|
WRVP22O-8X |
80 |
350 |
elettromagnetico |
AX/C1020 7/8-14 UNF |
WRVP22O-8-AX_400-P-122121-en |
|
WR22GP_SADB-10… |
80 |
350 |
monitoraggio della posizione tramite interruttore |
DD M24 x 1,5 |
WR22GPS-10-DD_400-P-131115-en |
|
WRV_22G-10A |
140 |
350 |
elettromagnetico |
HA/C1220 1 1/16-12 UN |
WRV22G-10A_400-P-131220-en |
|
WRV22O-10A-… |
140 |
350 |
elettromagnetico |
HA/C1220 1 1/16-12 UN |
WRV22O-10-HA_400-P-131221-en |
|
WRV22G-10F-… |
140 |
350 |
elettromagnetico |
HF/C1220A 1 1/16-12 UN |
WRV22G-10F_400-P-131210-en |
|
WRV22O-10F-… |
140 |
350 |
elettromagnetico |
HF/C1220A 1 1/16-12 UN |
WRV22O-10F_400-P-131211-en |
|
WRV22G-5H-… |
40 |
350 |
elettromagnetico |
BH/C0820 3/4-16 UNF |
WRV22G-5H_400-P-121150-en |
|
WRV22K-5H-… |
40 |
350 |
elettromagnetico |
BH/C0820 3/4-16 UNF |
WRV22K-5H_400-P-121155-en |
|
WRV22L-5H-… |
40 |
350 |
elettromagnetico |
BH/C0820 3/4-16 UNF |
WRV22L-5H_400-P-121156-en |
|
WRV22O-5H-… |
40 |
350 |
elettromagnetico |
BH/C0820 3/4-16 UNF |
WRV22O-5H_400-P-121151-en |
|
WR22GD-10... |
140 |
350 |
elettromagnetico |
DD M24 x 1,5 |
WR22GD-10_400-P-131111-en |
|
WR22GC-10... |
140 |
350 |
elettromagnetico |
DC M24 x 1,5 |
WR22GC-10_400-P-131110-en |
|
WR22_H-10… |
140 |
350 |
elettromagnetico |
DH M27 x 2 |
WR22H-10_400-P-131125-en |
|
WR22OC-10... |
140 |
350 |
elettromagnetico |
DC M24 x 1,5 |
WR22OC-10_400-P-131112-en |
|
WR22OD-10... |
140 |
350 |
elettromagnetico |
DD M24 x 1,5 |
WR22OD-10_400-P-131113-en |
|
WRA22GD-10... |
140 |
350 |
elettromagnetico |
DD M24 x 1,5 |
WRA22GD-10_400-P-131121-en |
|
WRA22OC-10... |
140 |
350 |
elettromagnetico |
DC M24 x 1,5 |
WRA22OC-10_400-P-131122-en |
|
WRA22OD-10... |
140 |
350 |
elettromagnetico |
DD M24 x 1,5 |
WRA22OD-10_400-P-131123-en |
|
WRA22GC-10... |
140 |
350 |
elettromagnetico |
DC M24 x 1,5 |
WRA22GC-10_400-P-131120-en |
|
WRV22G-12A-… |
180 |
350 |
elettromagnetico |
LA/C1620 1 5/16-12 UN |
WRV22G-12A_400-P-145130-en |
|
WRV22O-12A-… |
180 |
350 |
elettromagnetico |
LA/C1620 1 5/16-12 UN |
WRV22O-12A_400-P-145131-en |
|
WR22O-16... |
350 |
420 |
elettromagnetico |
EB M42 x 2 |
WR22O-16_400-P-150122-en |
|
WR22G-16... |
350 |
420 |
elettromagnetico |
EB M42 x 2 |
WR22G-16_400-P-150121-en |
|
|
W1U / X… (shallow) |
40 |
315 |
taratura manuale |
AC ad innesto |
W1U-W1X-installation-shallow_400-P-110315-en |
|
W1U / X… (deep) |
40 |
315 |
taratura manuale |
AD ad innesto |
W1U-W1X-installation-deep_400-P-110316-en |
|
W1V / Y… (shallow) |
40 |
315 |
taratura manuale |
AC ad innesto |
W1V-W1Y-installation-shallow_400-P-110317-en |
|
W1V / Y… (deep) |
40 |
315 |
taratura manuale |
AD ad innesto |
W1V-W1Y-installation-deep_400-P-110318-en |
|
W1S... |
40 |
315 |
pneumatico |
AC ad innesto |
W1S_400-P-110416-en |
|
W1R... |
40 |
315 |
pneumatico |
AC ad innesto |
W1R_400-P-110415-en |
|
EEx-W1D… |
20 |
315 |
elettromag. EEx |
AC ad innesto |
EExW1D,F-6_400-P-110215-en |
|
WS32G-5-AM |
22 |
250 |
elettromagnetico |
AM 3/4-16 UNF |
WS32G-5-AM_400-P-121200-en |
|
W1… |
40 |
315 |
descrizione |
|
W1-Overview_400-P-105010-en |
|
W1D (shallow) |
40 |
315 |
elettromagnetico |
AC ad innesto |
W1D-installation-shallow_400-P-110116-en |
|
W1D (deep) |
40 |
315 |
elettromagnetico |
AD ad innesto |
W1D-installation-deep_400-P-110117-en |
|
W1F…(shallow) |
40 |
315 |
elettromagnetico |
AC ad innesto |
W1F-installation-shallow_400-P-110119-en |
|
W1F…(deep) |
40 |
315 |
elettromagnetico |
AD ad innesto |
W1F-installation-deep_400-P-110120-en |
|
W1P32G... |
40 |
315 |
elettromagnetico |
AU/C1030 7/8-14 UNF |
W1P32G-8_400-P-112116-en |
|
W1N32G… |
40 |
315 |
elettromagnetico |
AU/C1030 7/8-14 UNF |
W1N32G-8_400-P-112115-en |
|
WSP32G-10-DN |
60 |
315 |
elettromagnetico |
DN M33 x 2 |
WSP32G-10-DN_400-P-131152-en |
|
|
WS42GNA-8… |
30 |
315 |
elettromagnetico |
AT/C1040 7/8-14 UNF |
WS42GNA-8-AT_400-P-126210-en |
|
|
WL22SD… |
150 |
420 |
controllo attivo |
DJ M27 x 2 |
WL22SD-10_400-P-140101-en |
|
WL22SDU / S1… |
150 |
420 |
controllo attivo |
DJ M27 x 2 |
WL22SDU-10_400-P-140111-en |
|
WL22SDL / R / P… |
150 |
420 |
controllo passivo |
DJ M27 x 2 |
WL22SDL,R,P-10_400-P-140121-en |
|
WL22SD… |
350 |
420 |
controllo attivo |
EB M42 x 2 |
WL22SD-16_400-P-160101-en |
|
WL22SDL… |
350 |
420 |
controllo passivo |
EB M42 x 2 |
WL22SDL-16_400-P-160121-en |
|
WL22SDUR… |
350 |
420 |
controllo passivo |
EB M42 x 2 |
WL22SDU-16_400-P-160151-en |
|
