Full Catalog: Counterbalance Valves

Technical Data

Symbol Type Flow
GPM		 Size
SAE
 Data sheet Model data CAD (STEP/IGS)

This unit is a direct acting, screw in cartridge style, poppet type, adjustable, pilot assisted, hydraulic counterbalance valve with free reverse and spring-chamber connected to tank.

 CBPA-08 10 08 CBPA-08_520-P-080510-en CAD (STEP/IGS)
CBPA-10 20 10 CBPA-10_520-P-080520-en CAD (STEP/IGS)
CBPA-12 35 12 CBPA-12_520-P-080530-en CAD (STEP/IGS)
CBPA-T-11A 20 10 CBPA-20M_520-P-081120-en CAD (STEP/IGS)

This unit is a direct acting, screw in cartridge style, poppet type, adjustable, pilot assisted, hydraulic counterbalance valve with free reverse, hydraulic dampening and spring-chamber connected to tank.

 CBPP-10 15 10 CBPP-10_520-P-081520-en CAD (STEP/IGS)
CBPP-T-11A 15 10 CBPP-10_520-P-081520-en CAD (STEP/IGS)

This unit is a line mounting body with 2 screw in cartridge style, direct acting, poppet type, adjustable, pilot assisted, hydraulic counterbalance valves with free reverse and spring-chamber connected to tank.

 DCBA-08 10 08 DCBA-08_520-P-080610-en CAD (STEP/IGS)
DCBA-10 20 10 DCBA-10_520-P-080620-en CAD (STEP/IGS)
DCBA-12 35 12 DCBA-12_520-P-080630-en CAD (STEP/IGS)

This unit is a direct acting, screw in cartridge style, poppet type, adjustable, pilot assisted, hydraulic counterbalance valve with free reverse, sealed pilot port and spring-chamber connected to tank.

 CBPS-08 10 08 CBPS-08_520-P-080710-en CAD (STEP/IGS)
CBPS-10 20 10 CBPS-10_520-P-080720-en CAD (STEP/IGS)
CBPS-12 35 12 CBPS-12_520-P-080730-en CAD (STEP/IGS)
CBPS-T-11A 20 10 CBPS-20M_520-P-081220-en CAD (STEP/IGS)

This unit is a line mounting body fitted with 2 screw in cartridge style, direct acting, poppet type, adjustable, pilot assisted, hydraulic counterbalance valves with free reverse, sealed pilot port and spring-chamber connected to tank.

 DCBS-08 10 08 DCBS-08_520-P-080810-en CAD (STEP/IGS)
DCBS-10 20 10 DCBS-10_520-P-080820-en CAD (STEP/IGS)
DCBS-12 35 12 DCBS-12_520-P-080830-en CAD (STEP/IGS)

This unit is a direct acting, screw in cartridge style, poppet type, adjustable, pilot assisted, hydraulic counterbalance valve with free reverse and vented spring chamber.

 CBPG-08 10 08 CBPG-08_520-P-080910-en CAD (STEP/IGS)
CBPG-10 20 10 CBPG-10_520-P-080920-en CAD (STEP/IGS)
CBPG-12 35 12 CBPG-12_520-P-080930-en CAD (STEP/IGS)
CBPG-T-11A 20 10 CBPG-20M_520-P-081320-en CAD (STEP/IGS)

This unit is a line mounting body fitted with 2 screw in cartridge style, direct acting, poppet type, adjustable, pilot assisted, hydraulic counterbalance valves with free reverse and vented spring chamber.

 DCBG-08 10 08 DCBG-08_520-P-081010-en CAD (STEP/IGS)
DCBG-10 20 10 DCBG-10_520-P-081020-en CAD (STEP/IGS)
DCBG-12 35 12 DCBG-12_520-P-081030-en CAD (STEP/IGS)
